X902D 9" Kit for Toyota Landcruiser 70 Series
    • Transform your Toyota LandCruiser 70 Series to a whole new level with Alpine’s all-new perfect fit solution, integrating a massive 9” navigation system into the dash. Equipped with a number of features you can enjoy Apple CarPlay, Android Auto, USB video and audio, DAB+ digital radio, Bluetooth music streaming, connected HDMI devices, navigation and much more.
    Built for the 4WD lifestyle, the embedded Hema navigation lets you explore your off-road adventures with topographical maps. Plus, Alpine’s premium navigation gives you high-resolution street maps with 3D city views, safety camera alerts and speed zones. What’s more, you can seamlessly route on-road to an off-road destination with Alpine 3D terrain off-road turn-by-turn navigation, and search to find the nearest caravan and campsites, off-road tracks and 4WD POIs.

    X902D 9" Kit for Toyota Landcruiser 70 Series

    SKU: LC70-X902D
    $3,599.00Price

    • Specifications

      Screen

      • Screen Size: 9-inch Capacitive WVGA
      • LCD Type: Transparent Type TN LCD
      • Operation System: TFT Active Matrix
      • Number of Picture Elements: 1,152,000 pixels (800 x 3 x 480)
      • Illumination System: White LED Backlighting
      • Effective Number of Picture Elements: 99.99%
      • Colour System: NTSC, PAL
      • Max Power Output Ratings
      • Max Power Output: 4 x 50 W

      FM Tuner

      • Tuning Range: 87.5 – 108.0 MHz
      • Mono Usable Sensitivity: 8.1 dBf (0.7 µV / 75 ohms)
      • 50dB Quieting Sensitivity: 12 dBf (1.1 µV / 75 ohms)
      • Alternate Channel Selectivity: 80 dB
      • Signal-to-Noise Ratio: 65 dB
      • Stereo Separation: 35 dB
      • Capture Ratio: 2 dB

      MW(AM) Tuner

      • Tuning Range: 531 – 1,602 kHz
      • Usable Sensitivity (IEC Standard): 25.1 µV / 28 dBf

      LW Tuner

      • Tuning Range: 153 – 281 kHz
      • Usable Sensitivity (IEC Standard): 31.6 µV / 30 dBf

      USB

      • USB Requirements: USB 2.0
      • Max. Power Consumption: 1,500 mA (CDP Support)
      • USB Class: Mass Storage Class, Play From Device
      • File System: FAT 16/32
      • MP3 Decoding: MPEG-1/2 AUDIO Layer-3
      • WMA Decoding: Windows Media™ Audio
      • AAC Decoding: ACC-LC format ′′.m4a′′ file
      • FLAC Decoding
      • Number of Channels: 2-Channel (Stereo)
      • Frequency Response: 5 – 20k Hz ±1 dB *Frequency Response may differ depending on the encoder software/bit rate
      • Total Harmonic Distortion (at 1kHz): 0.008%
      • DynamicRange(at 1kHz): 95 dB
      • Signal-to-Noise Ratio: 100 dB
      • Channel Separation (at 1kHz): 85 dB

      GPS/Glonass

      • GPS / Glonass compatible navigation antenna included

      BLUETOOTH®

      • BLUETOOTH® Version: Bluetooth V2.1+EDR
      • Output Power: +4 dBm Max. (Power class 2)
      • HFP: HFP (Hands Free Profile)
      • OPP (Object Push Profile)
      • PBAP (Phone Book Access Profile)
      • HSP (Head Set Profile)
      • A2DP: A2DP (Advanced Audio Distribution Profile)
      • AVRCP: AVRCP (Audio/Video Remote Control Profile)
      • SPP (Serial Port Profile)

      Sound Tuning

      • Subwoofer Level Adjustment: 0 to +15
      • Subwoofer Phase Setting: 0° or 180°
      • BASS ENGINE SQ: 5Mode, Level 0 to +6
      • HighPassFilter: 20 / 25 / 31.5 / 40 / 50 / 63 / 80 / 100 / 125 / 160 / 200 Hz
      • HighPassFilter (Slope): Off / -6 / -12 / -18 / -24 dB/oct.
      • HighPassFilter (Gain): -12 to 0 dB
      • LowPassFilter: 20 / 25 / 31.5 / 40 / 50 / 63 / 80 / 100 / 125 / 160 / 200 Hz
      • LowPassFilter (Slope): Off / -6 / -12 / -18 / -24 dB/oct.
      • LowPassFilter (Gain): -12 to 0 dB
      • Time Correction: 0.0 – 9.9ms (0.1ms step)
      • Dual HD EQ Front + Rear
      • Parametric Equalizer (Band 1): 20 – 100 Hz
      • Parametric Equalizer (Band 2): 63 – 315 Hz
      • Parametric Equalizer (Band 3): 125 – 500 Hz
      • Parametric Equalizer (Band 4): 250 – 1k Hz
      • Parametric Equalizer (Band 5): 500 – 2k Hz
      • Parametric Equalizer (Band 6): 1k – 4k Hz
      • Parametric Equalizer (Band 7): 2k – 7.2k Hz
      • Parametric Equalizer (Band 8): 5.8k – 12k Hz
      • Parametric Equalizer (Band 9): 9k – 20k Hz
      • Parametric Equalizer (Gain): -14 to +14
      • Application Volume Level Setting: -14 to +14

      HDMI Section

      • Input Format 720p/480p/VGA
      • Output Format 480p

      General

      • Power Requirement: 14.4 V. DC (11-16V allowable)
      • Pre Output Voltage (Before Clipping): 2 V / 10k ohms

      Dimensions

      • Display cable length: 100 cm
      • Key harness length: 25 cm
      • Din Size: 1DIN chassis and 9” Capacitive Touch Screen
      • Chassis Size (W x H x D) mm: 178 x 50 x 164 mm
      • Monitor size (W x H x D) mm: 214.7 x 136.6 x 32.45 mm
